codeql-javascript-multiflow

The primary purpose of this material is to serve as an introduction to CodeQL for Python. The section Reading Order describes the basic CodeQL queries to go through.

The Python code is intentionally trivial and mirrors the structure of production code. Further, the steps needed for CodeQL setup in production CI/CD pipelines have identical structure to the one shown here.

Thus, it is expedient to illustrate intermediate and advanced topics here as well. The section Additional Topics does this by illustrating descriptions from the CodeQL documentation using the Python code in this repository. Thus, the Additional Topics serve as additional examples to parts of the documentation. These additional topics should be read in the order of appearance.

For system administration and devops, the section CodeQL setup provides a rudimentary guide.

Node setup and Running Sequence

  npm i sqlite3

  node add-user.js

  ./admin  -c
  ./admin  -s

  echo frank | node add-user.js

  ./admin  -s

  echo 'Johnny"); DROP TABLE users; --' | node add-user.js

  ./admin  -s

CodeQL setup

It's best to have a full development setup for CodeQL on your laptop/desktop. This requires you to

download VS Code
install the CodeQL extension. Instructions on how to do that found here: https://codeql.github.com/docs/codeql-for-visual-studio-code/setting-up-codeql-in-visual-studio-code/
install a CodeQL binary (containing CodeQL CLI) for whichever platform you are on and unpack that The binary for 2.13.5 is found here: https://github.com/github/codeql-cli-binaries/releases/tag/v2.13.5 See script below.
use gh
```
  gh codeql set-version 2.15.2
```
(recommended for browsing) Install the codeql standard library matching the binary version. This is not needed to write or run queries anymore, but the library has many examples and searching it is much easier after extracting this archive: https://github.com/github/codeql/releases/tag/codeql-cli%2Fv2.13.5 See script below.

clone this repository.

  mkdir ~/local && cd ~/local && \
      git clone https://github.com/hohn/codeql-dataflow-sql-injection-python.git

open the workspace directory in VS Code. This should just be

  cd ~/local/codeql-dataflow-sql-injection-python
  code python-sqli.code-workspace

add the downloaded CodeQL CLI to the VS Code's search path. Find the CodeQL extension settings, then paste the full path to the CodeQL CLI into the
```
Code QL > Cli: Executable Path
```
field.

install the pack dependencies for the CLI. In a shell, use

  cd ~/local/codeql-javascript-multiflow/
  codeql pack install session
  codeql pack install solutions
  codeql pack install tests

  XX:  Does pack install use too-new libraries?
  0:$ rm session/codeql-pack.lock.yml
  (base)
  hohn@gh-hohn ~/local/codeql-javascript-multiflow
  0:$ codeql pack install session
  Dependencies resolved. Installing packages...
  Install location: /Users/hohn/.codeql/packages
  Package install location: /Users/hohn/.codeql/packages


  0:$ rm -fR /Users/hohn/.codeql/packages
  (base)
  hohn@gh-hohn ~/local/codeql-javascript-multiflow
  0:$ rm session/codeql-pack.lock.yml
  (base)
  hohn@gh-hohn ~/local/codeql-javascript-multiflow

  XX: no, same versions.

Run the tests.

  cd ~/local/codeql-javascript-multiflow/
  codeql test run tests/UltimateSource/UltimateSource.qlref

  gh codeql set-version 2.15.2
  codeql test run tests/UltimateSource/UltimateSource.qlref

  Executing 1 tests in 1 directories.
  Extracting test database in /Users/hohn/local/codeql-javascript-multiflow/tests/UltimateSource.
  Compiling queries in /Users/hohn/local/codeql-javascript-multiflow/tests/UltimateSource.
  Executing tests in /Users/hohn/local/codeql-javascript-multiflow/tests/UltimateSource.
  [1/1 comp 557ms eval 255ms] PASSED /Users/hohn/local/codeql-javascript-multiflow/tests/UltimateSource/UltimateSource.qlref
  Completed in 3s (extract 1.2s comp 557ms eval 255ms).
  All 1 tests passed.

  XX: with 2.13.5
  one troubleshooting step could be to run
  codeql resolve library-path --query=solutions/UltimateSource.ql
  to see which --dbscheme location it prints. Is
  the file at that location the same as the
  javascript/semmlecode.javascript.dbscheme in the unpacked CLI? (edited)

  0:$ gh codeql debug on

  0:$ codeql resolve library-path --query=solutions/UltimateSource.ql
  ++ dirname /Users/hohn/.local/share/gh/extensions/gh-codeql/gh-codeql
  + rootdir=/Users/hohn/.local/share/gh/extensions/gh-codeql
  ++ gh config get extensions.codeql.channel
  + channel=
  + :
  ++ gh config get extensions.codeql.version
  + version=v2.13.5
  + '[' resolve = local-version ']'
  ++ gh config get extensions.codeql.local-version
  + local_version=
  + :
  + '[' -e .codeql-version ']'
  + version=v2.13.5
  + '[' -z resolve ']'
  + '[' -z '' ']'
  + channel=release
  + repo=github/codeql-cli-binaries
  ++ gh config get extensions.codeql.platform
  + platform=
  + :
  + [[ -z '' ]]
  + [[ darwin23 == \d\a\r\w\i\n* ]]
  + platform=osx64
  + '[' resolve = debug ']'
  + '[' resolve = list-versions ']'
  + '[' resolve = set-channel ']'
  + '[' resolve = download ']'
  + '[' resolve = set-version ']'
  + '[' resolve = set-local-version ']'
  + '[' resolve = unset-local-version ']'
  + '[' resolve = list-installed ']'
  + '[' resolve = cleanup ']'
  + '[' resolve = cleanup-all ']'
  + '[' resolve = install-stub ']'
  + '[' -z v2.13.5 ']'
  + download v2.13.5
  + local version=v2.13.5
  + '[' -z v2.13.5 ']'
  + '[' v2.13.5 = latest ']'
  + '[' -x /Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5/codeql ']'
  + return 0
  + export CODEQL_DIST=/Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5
  + CODEQL_DIST=/Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5
  + exec /Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5/codeql resolve library-path --query=solutions/UltimateSource.ql
  --dbscheme=/Users/hohn/.codeql/packages/codeql/javascript-all/0.8.3/semmlecode.javascript.dbscheme
  --full-library-path=/Users/hohn/local/codeql-javascript-multiflow/solutions:/Users/hohn/.codeql/packages/codeql/javascript-all/0.8.3:/Users/hohn/.codeql/packages/codeql/javascript-queries/0.8.3:/Users/hohn/.codeql/packages/codeql/mad/0.2.3:/Users/hohn/.codeql/packages/codeql/regex/0.2.3:/Users/hohn/.codeql/packages/codeql/suite-helpers/0.7.3:/Users/hohn/.codeql/packages/codeql/tutorial/0.2.3:/Users/hohn/.codeql/packages/codeql/typos/0.2.3:/Users/hohn/.codeql/packages/codeql/util/0.2.3:/Users/hohn/.codeql/packages/codeql/yaml/0.2.3
  --no-default-compilation-cache
  --compilation-cache=/Users/hohn/.codeql/compile-cache

  # and manually
  export CODEQL_DIST=/Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5
  $CODEQL_DIST/codeql resolve library-path --query=solutions/UltimateSource.ql

  --dbscheme=/Users/hohn/.codeql/packages/codeql/javascript-all/0.8.3/semmlecode.javascript.dbscheme
  --full-library-path=/Users/hohn/local/codeql-javascript-multiflow/solutions:/Users/hohn/.codeql/packages/codeql/javascript-all/0.8.3:/Users/hohn/.codeql/packages/codeql/javascript-queries/0.8.3:/Users/hohn/.codeql/packages/codeql/mad/0.2.3:/Users/hohn/.codeql/packages/codeql/regex/0.2.3:/Users/hohn/.codeql/packages/codeql/suite-helpers/0.7.3:/Users/hohn/.codeql/packages/codeql/tutorial/0.2.3:/Users/hohn/.codeql/packages/codeql/typos/0.2.3:/Users/hohn/.codeql/packages/codeql/util/0.2.3:/Users/hohn/.codeql/packages/codeql/yaml/0.2.3
  --no-default-compilation-cache
  --compilation-cache=/Users/hohn/.codeql/compile-cache

  0:$ find $CODEQL_DIST | grep 'javascript/semmlecode.javascript.dbscheme'
  /Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5/javascript/semmlecode.javascript.dbscheme
  /Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5/javascript
  /semmlecode.javascript.dbscheme.stats

  0:$ cmp /Users/hohn/.codeql/packages/codeql/javascript-all/0.8.3/semmlecode.javascript.dbscheme \
      /Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5/javascript/semmlecode.javascript.dbscheme
  /Users/hohn/.codeql/packages/codeql/javascript-all/0.8.3/semmlecode.javascript.dbscheme /Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5/javascript/semmlecode.javascript.dbscheme differ: char 3917, line 165

  1:$ diff /Users/hohn/.codeql/packages/codeql/javascript-all/0.8.3/semmlecode.javascript.dbscheme     /Users/hohn/.local/share/gh/extensions/gh-codeql/dist/release/v2.13.5/javascript/semmlecode.javascript.dbscheme
  165d164
  < | 40 = @using_decl_stmt
  168c167
  < @decl_stmt = @var_decl_stmt | @const_decl_stmt | @let_stmt | @legacy_let_stmt | @using_decl_stmt;
  ---
  > @decl_stmt = @var_decl_stmt | @const_decl_stmt | @let_stmt | @legacy_let_stmt;

install the pack dependencies VS Code. Do this via
```
command palette
```
and then select all listed by
```
CodeQL: Install Pack Dependencies
```
It will generate a codeql-pack.lock.yml file.

use the following to build a CodeQL database.

  #* Build the db with source commit id.
  codeql --version
  : CodeQL command-line toolchain release 2.13.5.

  cd ~/local/codeql-javascript-multiflow/

  DB=./js-sqli-db-$(git rev-parse --short HEAD)
  echo $DB

  test -d "$DB" && rm -fR "$DB"
  mkdir -p "$DB"

  codeql database create --language=javascript -s . -j 8 -v $DB

  # Check it
  unzip -v $DB/src.zip |egrep '(add|sample)'

add the database to the editor. To do this there is a widget on the left side of editor that looks like QL and after selecting that, there is a databases panel. There are options to select from archive or folder. Select the "from folder" option and add the "database" folders you created above.

open the query trivial.ql and run it via

right click > run query on selected database

There are several ways to install the CodeQL binaries and libraries. Here is a shell script to do it one way

  # grab -- retrieve and extract codeql cli and library
  # Usage: grab version platform prefix
  grab() {
      version=$1; shift
      platform=$1; shift
      prefix=$1; shift
      mkdir -p $prefix/codeql-$version &&
          cd $prefix/codeql-$version || return

      # Get cli
      wget "https://github.com/github/codeql-cli-binaries/releases/download/$version/codeql-$platform.zip"
      # Get lib
      wget "https://github.com/github/codeql/archive/refs/tags/codeql-cli/$version.zip"
      # Fix attributes
      if [ `uname` = Darwin ] ; then
          xattr -c *.zip
      fi
      # Extract
      unzip -q codeql-$platform.zip
      unzip -q $version.zip
      # Rename library directory for VS Code
      mv codeql-codeql-cli-$version/ ql
      # remove archives?
      # rm codeql-$platform.zip
      # rm $version.zip
  }

  # Try:
  grab v2.13.5 osx64 $HOME/local/xefm

  grab v2.13.5 linux64 $HOME/local/xefm

  ls $HOME/local/xefm/codeql-v2.13.5/
  : codeql/  codeql-osx64.zip  ql/  v2.13.5.zip

Sample Application Setup and Run

Execute the following in a bourne-style shell, one block at a time to see results. This requires a working Python installation and a POSIX shell.

  # Prepare db
  ./admin -r
  ./admin -c
  ./admin -s

  # Add regular user
  ./add-user.py 2>> log
  First User

  # Check
  ./admin -s

  # Add Johnny Droptable
  ./add-user.py 2>> log
  Johnny'); DROP TABLE users; --

  # See the problem:
  ./admin -s

  # Check the log
  tail log

Reading Order

The queries introduce CodeQL concepts and should be read bottom-up in this order:

source.ql: introduces Value, ControlFlowNode and DataFlow::Node.
sink.ql: introduces AstNode.
TaintFlowTemplate.ql: introduce the taint flow template.
TaintFlow.ql: taint flow with endpoints only, using a class. This is the old way, but it still works and is a good introduction to using classes – not writing them.
TaintFlowPath.ql: taint flow with full path. Again, the old way.
TaintFlowWithModule.ql: taint flow with endpoints only, using modules. The way forward.
TaintFlowPathQueryWithModule.ql: taint flow with full path, using modules.

Note on the Python code

The Python call

conn.execute(query)

to sqlite3 only allows one statement and produces an exception:

sqlite3.Warning: You can only execute one statement at a time.

This makes it safer than the raw

sqlite3_exec()

or Python's

conn.executescript

For this tutorial, we use the multi-statement executescript() call.

Additional Topics

This repository and its source code are used to illustrate some additional topics from the CodeQL Python documentation.

Dataflow in Python

https://codeql.github.com/docs/codeql-language-guides/analyzing-data-flow-in-python/

Using and extending the CodeQL standard library:

StdLibPlain.ql Illustrates using the CodeQL standard library's
```
RemoteFlowSource
```

StdLibExt.ql Illustrates extension of the CodeQL standard library via

class SqlAccess extends FileSystemAccess::Range ...

and

class TerminalInput extends RemoteFlowSource::Range ...

Various data flow / taint flow examples from the documentation, modified as needed:

using-local-data-flow.ql
using-local-sources.ql
using-local-taint-tracking.ql

API graphs

https://codeql.github.com/docs/codeql-language-guides/using-api-graphs-in-python/

API graphs are a uniform interface for referring to functions, classes, and methods defined in external libraries.

ApiGraphs.ql: various sample queries

Type Tracking

Documentation for JavaScript, also applicable here: https://codeql.github.com/docs/codeql-language-guides/using-type-tracking-for-api-modeling/#using-type-tracking-for-api-modeling

The files

sqlite-info.py
TypeTracking.ql

use type tracking. From the docs: You can track data through an API by creating a model using the CodeQL type-tracking library. The type-tracking library makes it possible to track values through properties and function calls.

The file

TypeTrackingWithData.ql

goes further. From the docs: The type-tracking library makes it possible to track values through properties and function calls. Here, we also track some associated data. See https://codeql.github.com/docs/codeql-language-guides/using-type-tracking-for-api-modeling/#tracking-associated-data

Flow State

The query TaintFlowPathQueryWithSanitizer.ql illustrates using a flow-state representing whether user input has been sanitized.

It introduces ADTs via the newtype declaration of TInputSanitizationState.

README.org Unescape Escape

SQL injection example
